Image shown is a representation only. Exact specifications should be obtain- ed from the product data sheet.

Rubycon 8SW100M


Manufacturer Part Number : 8SW100M
Manufacturer : Rubycon
Description : CAP ALUM POLY 100UF 20% 8V SMD
Lead Free Status / RoHS Status : Lead free / RoHS Compliant
Datasheet : 8SW100M.PDF 8SW100M PDF
EDA / CAD Models : 8SW100M by SnapEDA
Stock Condition :In Stock 1267, New Original
Quantity:
Delivery:
Payment:
157 202 688750 /DataSheets/Capacitors/SLG_SWZ_SW_Series.pdf Rubycon/8SW100M 688750
Part Status:Obsolete
Type:Polymer
Capacitance:100μF
Tolerance:±20%
Voltage - Rated:8V
ESR (Equivalent Series Resistance):18 mOhm
Lifetime @ Temp#:2000 Hrs @ 105°C
Operating Temperature:-55°C ~ 105°C
Applications:General Purpose
Ripple Current @ Low Frequency:-
Ripple Current @ High Frequency:2.5A @ 100kHz
Lead Spacing:-
Size / Dimension:0.287" L x 0.169" W (7.30mm x 4.30mm)
Height - Seated (Max):0.106" (2.70mm)
Surface Mount Land Size:0.287" L x 0.169" W (7.30mm x 4.30mm)
Mounting Type:Surface Mount
Package / Case:2917 (7343 Metric)

Request for Quotation


Please fil the form and we'll get back to you within 24 hours.

Technical Parameters of 8SW100M

Part Status:Obsolete
Type:Polymer
Capacitance:100μF
Tolerance:±20%
Voltage - Rated:8V
ESR (Equivalent Series Resistance):18 mOhm
Lifetime @ Temp#:2000 Hrs @ 105°C
Operating Temperature:-55°C ~ 105°C
Applications:General Purpose
Ripple Current @ Low Frequency:-
Ripple Current @ High Frequency:2.5A @ 100kHz
Lead Spacing:-
Size / Dimension:0.287" L x 0.169" W (7.30mm x 4.30mm)
Height - Seated (Max):0.106" (2.70mm)
Surface Mount Land Size:0.287" L x 0.169" W (7.30mm x 4.30mm)
Mounting Type:Surface Mount
Package / Case:2917 (7343 Metric)

Product Details

We can supply Rubycon part# 8SW100M, use the request quote form to request 8SW100M pirce and lead time. Nantian Electronics - ntchip.com is an independent stocking distributor of electronic components. With 3+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 8SW100M. The price and lead time for 8SW100M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 8SW100M. We look forward to doing business with you.
