Image shown is a representation only. Exact specifications should be obtain- ed from the product data sheet.

Sanken BR204

Manufacturer Part Number : BR204
Manufacturer : Sanken
Description : IC MODULE DC/DC CONV 10A
Lead Free Status / RoHS Status : Lead free / RoHS Compliant
Datasheet : BR204.PDF BR204 PDF
EDA / CAD Models : BR204 by SnapEDA
Quantity:
398 402 6846444 http://www.semicon.sanken-ele.co.jp/sk_content/br204_ds_en.pdf Sanken/BR204 6846444

Request for Quotation

Technical Parameters of BR204

Series:-
Type:Non-Isolated PoL Module
Number of Outputs:1
Voltage - Input (Min):10.8V
Voltage - Input (Max):13.2V
Voltage - Output 1:1.6 ~ 5.5 V
Voltage - Output 2:-
Voltage - Output 3:-
Current - Output (Max):10A
Power (Watts) - Manufacture Series:55W
Voltage - Isolation:-
Applications:ITE (Commercial)
Features:Remote On/Off, OCP
Mounting Type:Surface Mount
Package / Case:10-SMD Module
Size / Dimension:0.80" L x 0.45" W x 0.17" H (20.3mm x 11.4mm x 4.2mm)
Operating Temperature:-40~C ~ 85~C
Efficiency:95.10%

Product Details

We can supply Sanken part# BR204, use the request quote form to request BR204 pirce and lead time. Nantian Electronics - ntchip.com is an independent stocking distributor of electronic components. With 3+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number BR204. The price and lead time for BR204 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# BR204. We look forward to doing business with you.
