Cree Wolfspeed C4D02120E-TR

Manufacturer Part Number : C4D02120E-TR
Manufacturer : Cree Wolfspeed
Description : DIODE SCHOTTKY 1.2KV 9A TO252-2
Lead Free Status / RoHS Status : Lead free / RoHS Compliant
Datasheet : C4D02120E-TR.PDF C4D02120E-TR PDF
EDA / CAD Models : C4D02120E-TR by SnapEDA
Quantity:
1780 1802 3666743 /datasheets/Discrete Semiconductor Products/C4D02120E-TR-3666743.pdf Cree-Wolfspeed/C4D02120E-TR 3666743
TypeDescription
CategoryDiscrete Semiconductor Products Diodes Rectifiers Single Diodes
MfrWolfspeed, Inc.
SeriesZ-Rec®
PackagingTape & Reel (TR)
Part StatusActive
TechnologySiC (Silicon Carbide) Schottky
Voltage - DC Reverse (Vr) (Max)1200 V
Current - Average Rectified (Io)10A
Voltage - Forward (Vf) (Max) @ If1.8 V @ 2 A
SpeedNo Recovery Time > 500mA (Io)
Reverse Recovery Time (trr)0 ns
Current - Reverse Leakage @ Vr50 µA @ 1200 V
Capacitance @ Vr, F167pF @ 0V, 1MHz
Grade-
Qualification-
Mounting TypeSurface Mount
Package / CaseTO-252-3, DPAK (2 Leads + Tab), SC-63
Supplier Device PackageTO-252-2
Operating Temperature - Junction-55°C ~ 175°C
Base Product NumberC4D02120


The Cree Wolfspeed C4D02120E-TR is an innovative 1.2kV Schottky rectifier, designed with a streamlined focus on efficient and reliable performance. This component is distinguished by remarkable features such as zero reverse recovery current and high-frequency operation, offering a seamless performance with minimal interruptions. A standout element is its temperature-independent switching behavior that ensures consistent performance irrespective of ambient conditions. Furthermore, the rectifier shines with its extremely fast switching, made even more reliable due to a positive temperature coefficient on VF, adding valuable safety and stability elements to the design.

Cree Wolfspeed C4D02120E-TR part picture

Given its unique set of attributes, the C4D02120E-TR can be used in a diverse range of applications. These include, but are not limited to, switch mode power supplies (SMPS) and boost diodes in PFC or DC/DC stages. It also serves as free-wheeling diodes in inverter stages, and as a reliable component in LED lighting power supplies and AC/DC converters. Whether for high-level industrial applications or more specialized electronics, this Schottky rectifier serves as a reliable and adaptable solution.

Cree Wolfspeed C4D02120E-TR Package Original Label

Cree Wolfspeed C4D02120E-TR Package Original Label

Nantian Electronics, a reputable distributor of Cree Wolfspeed components, carries a substantial stock of the C4D02120E-TR. To simplify its integration, a detailed datasheet, pin diagram instructions, and complete component parameters are readily available for download.
