Introduction to the NL453232T-391J-PF Inductor by TDK Corporation
The NL453232T-391J-PF, developed by TDK Corporation, is a meticulously designed wirewound inductor that plays a critical role in the performance and reliability of RF (Radio Frequency) and standard electronic circuits. This unshielded inductor is known for its high inductance value and precision, making it an essential component in a wide array of electronic devices. It is engineered to provide stability and efficiency, enhancing the functionality of electronic circuits with its consistent performance.
TDK is the manufacturer of the NL453232T-391J-PF, which is available in stock at Nantian. The reference price for NL453232T-391J-PF can be found by referring to TDK or Nantian's listings. For detailed parameters and understanding its functionality, you can refer to the NL453232T-391J-PF datasheet PDF and pin diagram description that are available for download.
The NL453232T-391J-PF has a wide range of applications as outlined in DSP Datasheet PDF. To further understand how it works, you can find usage methods along with circuit diagrams within these resources. For comprehensive electronics tutorials on using this component, these documents should prove highly beneficial.
All relevant information including datasheets, pin diagrams, circuit diagrams and tutorials related to NL453232T-391J-PF could be downloaded from Nantian's platform.
Key Features
Inductance value of 390 uH, catering to specific electronic applications that demand a high level of inductance.
5% tolerance, ensuring precise and stable performance across various operating conditions.
Maximum DC current capability of 80 mA, suitable for a broad range of applications without the risk of saturation.
Maximum DC resistance of 16 Ohms, optimizing power efficiency by minimizing losses.
Q Minimum of 40 at a self-resonant frequency of 3 MHz, indicating efficient energy storage and minimal losses at operational frequencies.
Technical Specifications
Unshielded design, ideal for applications where magnetic interference is not a primary concern.
Operating temperature range from -40°C to +85°C, ensuring reliable performance under a wide range of environmental conditions.
Ferrite core material, providing excellent magnetic characteristics for RF and other electronic circuits.
Dimensions: 4.5 mm in length, 3.2 mm in width, and 3.4 mm in height, allowing for easy integration into compact circuit designs.
Standard PCB mount and SMD/SMT termination style, facilitating straightforward mounting and soldering processes.
Applications and Integration
TDK's NL453232T-391J-PF inductor finds extensive use in RF applications, power supply circuits, and various electronic devices requiring precise inductance values. Its wirewound construction and ferrite core are optimized for high efficiency and minimal energy loss, making it an excellent choice for designers focused on enhancing circuit performance and reliability. The inductor's compatibility with standard PCB mount techniques and its operational temperature range enable its use in a diverse range of products, from consumer electronics to automotive and industrial equipment.
